OpticPro LED Sports Floodlight - 1800W

  • Sale
  • Regular price

The OpticPro sports floodlights are the latest generation of high powered LED floodlights from Integrated Power. Their wide range of precision optics and accessories make them adaptable to even the most demanding sports lighting projects. The highly adjustable mounting bracket is cleverly designed to make installation straight forward, whether standard or underslung mounting is required.


  • Heavy duty construction
  • High efficiency LED chips and drivers
  • Large range of asymmetric & symmetric optics
  • Glare and spill light shield accessories
  • Top & underslung crossarm mountable
  • Bird protection
  • DC junction box / remote driver
  • DALI2 / DMX Dimming inputs
  • DC cable required for remote driver installation (not supplied)


  • Sports Lighting
  • Hard Stands
  • Industrial Sites
  • Security Lighting
  • Signage

Standard Specifications

Rated Input Power: 1800W Input Voltage: AC 100 - 277V
Lumen Output: 264,600lm CRI Rating: CRI>70 (CRI>80, CRI>90 optional)
Colour Temperature: 5000K (4000K, 5700K Optional) SDCM Rating: < 5
IK Rating: IK09 IP Rating: IP66
EPA (Sail Area): 0.1m² 0° tilt Service Life: L70 >100,000hrs
Fitting Weight: 40.0kg (without driver)



 2.5m² 6 Core + Earth circular cable required for DC connection between fitting and driver (not supplied)


IES Files

IES OP1800GR5KD01 12deg SYM - 1800W
IES OP1800GR5KD02 16deg SYM - 1800W
IES OP1800GR5KD03 30deg SYM - 1800W
IES OP1800GR5KD04 60deg SYM - 1800W
IES OP1800GR5KD05 60x130deg WB ASYM - 1800W
IES OP1800GR5KD06 40x130deg MB ASYM - 1800W
IES OP1800GR5KD07 25x130deg NB ASYM - 1800W
IES OP1800GR5KD08 AS-L ASYM - 1800W
IES OP1800GR5KD09 AS-R ASYM - 1800W
IES OP1800GR5KD10 AS-LR ASYM - 1800W



Model Option Stock Code Availability
Grey / 12 deg SYM OP1800GR5KD01 Special Order
Grey / 16 deg SYM OP1800GR5KD02 Special Order
Grey / 30 deg SYM OP1800GR5KD03 Special Order
Grey / 60 deg SYM OP1800GR5KD04 Special Order
Grey / 60x130 deg WB ASYM OP1800GR5KD05 Special Order
Grey / 40x130 deg MB ASYM OP1800GR5KD06 Special Order
Grey / 25x130 deg NB ASYM OP1800GR5KD07 Special Order
Grey / AS-L ASYM OP1800GR5KD08 Special Order
Grey / AS-R ASYM OP1800GR5KD09 Special Order
Grey / AS-LR ASYM OP1800GR5KD10 Special Order
Special order products typically have an 12-14 week lead time. Minimum order qty's may apply.
