The CF series LED floodlight is a powerful yet compact commercial LED fitting. With high spec Philips LED chips and specialised secondary optics to minimise light spillage, the CF Series flood is the ultimate commercial LED floodlight.
Features
- Heavy duty construction
- Flicker free driver
- High Efficiency Lumiled Chips
- High efficiency Philips LED chips
- Specialised optics available
- Full range of motion on mounting bracket
- 1.5 cable with AU plug
Applications
- Sports lighting
- Hard stands
- Security lighting
- Signage
Standard Specifications
| Input Voltage: 220 - 240 Vac | Rated Input Power - 150W |
| Lumen Output - 21,000lm | Colour Temperature - 5000K (4000K, 3000K optional) |
| CRI Rating: CRI>80 (*CRI > 85 / GS) | SDCM Rating: < 3 |
| IP Rating - IP66 | IK Rating - IK08 |
| Service Life: L70>50,000hrs | Optics - Asymmetric Lens |
| Luminaire Weight - 4.5 kg |
Option List
| 0 - 10V Dimming | / 0-10V |
| DALI Dimming | / DALI |
| Greenstar Specification* | / GS |
Accessories
| Pole Bracket Adaptor - 60mm | CFPBR01 |
| Pole Clamp Bracket - 40mm to 150mm | CFCL150B |
| Protective Wire Mesh Cover | CF2150PWM01 |
IES Files
| IES CF2150BL5KN01 150W ASYM |
Models
| Model Option | Stock Code | Availability |
|---|---|---|
| Black / 4000K | CF2150BL4KN01 | Stock Item |
| Black / 5000K | CF2150BL5KN01 | Stock Item |
| Special order products typically have an 12-14 week lead time. Minimum order qty's may apply. | ||
