PB Series Low Glare Backlit LED Panels 36W - 600x600mm

  • Sale
  • Regular price $0.00


The PB Series Low Glare backlit LED panels balance high output with clean, even light distribution. These panels not only reduce glare, but include flicker free drivers adding an extra layer of visual comfort in the workplace. They are a stylish troffer replacement for standard grid ceilings. Perfect for either retrofits or new buildings.


Features

  • UGR<19 Low Glare Capable
  • High Quality LED Chips & Drivers
  • Wide beam SMD LED technology
  • Dimmable & DALI Options
  • Multiple Mounting Options
  • Replaces 2x 36W Fluorescent Troffer
  • Selectable Colour Temperatures


Applications

  • Offices
  • Conference Rooms
  • Schools
  • Foyers
  • Retail Stores
  • Shopping Centres


Standard Specifications

Rated Input Power: 36W Beam Angle: 120 Degree
Lumen Output: 3240-3600lm CRI>80
Colour Temp: 3000/4000/5700K UGR <19
IP Rating: IP20



Options

Mains Dimmable /DIM
DALI Dimmable
/DALI



Accessories

Surface Mount Kit PB1WHN03
Recessed Kit PA1WHN04
Wire Suspension Kit PA1SIN01
Indoor Motion Sensor - Surface Mount SE1WHN01
Indoor Motion Sensor - Recessed Mount SE1WHN02
Indoor Motion Sensor - Presence Surface Mount SE1WHN03
Indoor Motion Sensor - High Ceiling SE1WHN04



IES Files

IES PB136WHXKN02 UGR 600x600 36W 3000K
IES PB136WHXKN02 UGR 600x600 36W 4000K
IES PB136WHXKN02 UGR 600x600 36W 5700K



Models

Model Option Stock Code Availability
UGR<19 Low Glare PB136WHXKN02 Stock Item
Special order products typically have an 12-14 week lead time. Minimum order qty's may apply.
