DL Series Tri-Colour LED Downlight - 13W

  • Sale
  • Regular price $0.00

Integrated Power’s DL Series LED downlights offer high spec features in a compact, stylish fitting. With great colour rendition (CRI80+) and compatibility with a wide range of Australian dimmers, they are the perfect choice for a wide range of lighting applications.


  • Wide beam SMD LED technology
  • High output LED chips
  • Mains dimmable driver
  • IP 54 when installed
  • Colour selectable


  • Residential
  • Offices
  • Foyers
  • Passageways
  • Bathrooms

Standard Specifications

Rated Input Power: 13W Lumen Output: 900lm - 1120lm
Beam Angle: 90° Colour Temperature: 3000K / 4000K / 5700K
CRI Rating: CRI>80 SDCM Rating: < 6 (lower bins available)
IP Rating: IP54 Cutout: 90-100mm
Dimensions: Ø110*38mm


Options (add option to end of stock code)

DALI Dimming  /DALI
Greenstar Specification /GS



13W White Adaptor Ring - 140mm DLADP01
13W White Adaptor Ring - 168mm DLADP02
Indoor Motion Sensor - Surface Mount SE1WHN01
Indoor Motion Sensor - Recessed Mount SE1WHN02
Indoor Motion Sensor - Presence Surface Mount SE1WHN03
Indoor Motion Sensor - High Ceiling SE1WHN04
Outdoor Motion Sensor - Microwave SE1WHN05
Outdoor Motion Sensor - Infrared SE1WHN06


IES Files

IES DL13WH3KD01 13W 3000K

IES DL13WH4KD01 13W 4000K

IES DL13WH5KD01 13W 5700K




Model Option Stock Code Availability
White / 3CCT Selectable DL13WHXKD01 Stock Item
Special order products typically have an 12-14 week lead time. Minimum order qty's may apply.
