The HFS Series Floodlights are the next generation in high output Sports & Area Lighting. With low windage, asymmetric optics options and wattages ranging from 240W - 600W, the HFS Series is the ideal fitting to meet the required lighting standards for your specific sporting application.
Features
- Heavy Duty Construction
- Directly replace up to 1500W MH fittings
- Asymmetrical optic design
- Glare and spill light shielding
- Backlight control
- Robust mounting system, fully adjustable
- Multiple mounting options
Applications
- Tennis Courts
- Sporting
- Hardstands
- Industrial Sites
Standard Specifications
| Rated input power - 600W | IP66 |
| High Efficiency SMD chips | Lumens - 87,000lm |
| EPA (Sail Area) - 0.448m² | Colour Temp - 5000K |
| Weight - 18.0kg |
Options (add option to end of stock code)
| PE Cell | /PE |
| 0-10V Dimming | /0-10 |
Accessories
| U Bracket - 450/600W models | HFS1BR02 |
| Vertical Pole Mount - 60mm | HFS1VPM01 |
| Horizontal Pole Mount - 60mm | HFS1HPM01 |
| Straight Arm Mount | HFS1SAM01 |
IES Files
| IES HFS600BK5KN01 T2M 600W |
| IES HFS600BK5KN02 T3M 600W |
| IES HFS600BK5KN03 T4M 600W |
| IES HFS600BK5KN04 T5M 600W |
| IES HFS600BK5KN05 NEMA 3x3 600W |
| IES HFS600BK5KN06 NEMA 6x4 600W |
Models
| Model Option | Stock Code | Availability |
|---|---|---|
| Black / T2 M | HFS600BK5KN01 | Special Order |
| Black / T3 M | HFS600BK5KN02 | Special Order |
| Black / T4 M | HFS600BK5KN03 | Special Order |
| Black / T5 M | HFS600BK5KN04 | Special Order |
| Black / NEMA 3x3 | HFS600BK5KN05 | Special Order |
| Black / NEMA 6x4 | HFS600BK5KN06 | Special Order |
| Special order products typically have an 12-14 week lead time. Minimum order qty's may apply. | ||
