The OmniBend LED RGB Striplight delivers seamless, dot-free illumination designed for commercial and architectural spaces. Engineered for efficiency, durability, and versatility, this strip offers SPI pixel-level control to provide seamless animations, vibrant colour transitions, and precise lighting effects to suit both indoor and protected outdoor applications. From retail and hospitality to signage, offices, and event spaces, the OmniBend RGB StripLight is the luminaire that does it all with consistent, brilliant performance.
Features
- Brilliant SPI-RGB pixel control
- Advanced GS8206 IC with breakpoint transmission
- Seamless colour changing technology
- Low power consumption design
- Flexible cutting for custom lengths
- High lumen output per metre
- Wide illumination beam angle
- Dynamic & precise RGB colours
- Durable 10mm PCB with 3oz copper foil
- Quick installation with 3M adhesive backing
- Flexible design
- Supplied in standard 5m lengths
Applications
- Architectural
- Exterior & Interior Decorative Lighting
- Façade Lighting
- Artworks
- Cove Lighting
- Feature Lighting
- Signage
Standard Specifications
| Rated Power: 13W/M (15W/M Max) | Input Voltage: 24Vdc |
| Input Current: 0.54A | Dimensions: 10mm (W) x 2.1mm (H) |
| Colour Temperature: RGB | Control: SPI-RGB (10 x pixels/m IC-GS8206) |
| Lumen Output @ RGB: 455lm/m | Beam Angle: 120° |
| LED Quantity: 60 LEDs/m | Minimum Cut: 100mm |
| Minimum Bend Diameter: Ø60mm | Standard Connector: Factory Fitted Single Glued End Cap Cable Entry |
| Wire Length: 2 Metres (SM Male & Female Cable) Factory Fitted | Packing Length: 5 Metres (Max Run Length) |
| IP Rating: IP20 | Operating Temperature: 0℃ ~ 40℃ |
| Warranty: 3 Years |
Options
LED Length Options
| 10 Metre Roll (Dual Connector Required) |
| Customizable Lengths |
Colour Temperature Options
| R |
| G |
| B |
Connector Wire Options
| 12cm |
| 20cm |
| 25cm |
| 50cm |
| 100cm |
| 200cm |
| Customizable Lengths |
Control Options
| Casambi Control | / CAS |
| PWM Control | / PWM |
| DMX Control | / DMX |
IES Files
| IES file available on request |
Cable Entry Options
|
Single Cable Entry
|
 |
|
Dual Cable Entry
|
 |
Accessories
 |
LED Strip Fast Connector Straight 10mm - 4 Pin | OBACBB410-NOTA |
 |
LED Fast Connector Cable to Strip 10mm - 4 Pin | OBACXB410-NOTA |
 |
Silicone Plug Kit - 8mm | OBADT08EA-A |
 |
Silicone Plug Set - 8mm | OBADW08EA-A |
 |
Silicone Plug Kit - 10mm | OBADT10EA-A |
 |
Silicone Plug Set - 10mm | OBADW10EA-A |
 |
Silicone Clip - 10mm | OBAFSW10SA |
 |
Silicone Gel Glue - LED Strip | OBAAS-PG-003 |
Models
| Model Option | Stock Code | Availability |
|---|---|---|
| RGB LED Strip 13W/M C/W 2M Cable IP20 12mm SPI 5M Roll | OBS5T13RGB10/01/SPI | Stock Item |
| Special order products typically have a 10-12 week lead time. Minimum order qty's may apply. Please contact us to confirm. | ||
