TR Series LED Tracklights - Linear Black 1500mm

  • Sale
  • Regular price

The TR Tracklight Series is specially designed to fit smoothly into restaurants, high-end shopping centres and many other retail environments. The TR Series linear fittings can be installed as seamless linear runs, positioned individually or even mixed with spotlights and many other track mounted fittings. The plug and play versatility makes repositioning a breeze for the end user.

Please contact us directly for specific details on our TR Tracklight Series.


  • High lumen efficiency 160lm/W
  • Seamless linear design
  • Flicker free driver
  • Power selectable - 35W, 40W, 45W & 50W
  • 3 Channel switchable
  • Easy installation and assembly
  • Surface and suspension mountable
  • Service life >50,000 hours


  • Restaurants
  • Shop Fronts
  • Retail Stores
  • Display Windows
  • Museum Displays
  • Hotels


Standard Specifications

Rated Input Power: 35W - 50W (selectable) Lumen Output: 8000lm (max)
Colour Temp: 3000K/4000K/5000K Beam Angle: 90 Degrees
CRI: Ra>80 IP Rating: IP20

Options (add option to end of stock code)

DALI Dimming



3 Channel 2 Metre Track, Black TRT2M3CBK
3 Channel 3 Metre Track, Black TRT3M3CBK
3 Channel Track Connector, Black  TRTCON3CBK
3 Channel Powered End Cap, Black  TRTPOWEC3CBK
3 Channel End Cap, Black  TRTEC3CBK
3 Channel L Connector (angle adjustable), Black TRTCONL3CBK
3 Channel T Connector (left), Black TRTCONTL3CBK
3 Channel T Connector (right), Black TRTCONTR3CBK
3 Channel 4-way Connector, Black TRTCON4WAY3CBK
1.5m Wire Suspension Kit, Black TRT1.5WSKBK
T-Bar Mounting Clip, Black TRT1TBARBK


IES Files

IES TRL50BK4KN01 90deg 50W
IES TRL50BK4KN01 90deg 45W
IES TRL50BK4KN01 90deg 40W
IES TRL50BK4KN01 90deg 35W


Model Option Stock Code Availability
Black / 3000K TRL50BK3KN01 Special Order
Black / 4000K TRL50BK4KN01 Stock Item
Black / 5000K TRL50BK5KN01 Special Order
Special order products typically have an 12-14 week lead time. Minimum order qty's may apply.
